Roll Cage Kit Upgrade to Package Shelf Version (90-05)

Modify your standard MiataCage kit to mount to the package shelf instead of the floor.
Free shipping
$275.00
- +

All the parts needed to modify the standard   Miata Cage Kit (Not Included) to a version that mounts to the package shelf.

The way this package works is you utilize most all of the parts from the standard floor mount MiataCage Roll Cage Kit and then we supply you with the following to convert it to a package shelf mount.

  • Package Shelf Installation Addendum.  12 pages with pictures and schmatic.
  • (2) Laser cut and formed Main Hoop and Lower Door Bar landing plates
  • 1" Tube Gussets
  • Main Hoop Taco Gusset
  • Fire Plates
  • Re-designed Kill Switch mounting plate
  • (2) New Upper Door Bars
  • Free Shipping in the continental US via UPS Ground service.

The only parts you will not use from the standard Roll Cage Kit would be the upper Nascar bars and the kill switch plate.



Given the location of the main hoop diagonal when installing the main hoop to the package shelf, we felt it necessary to include in the kit the Taco Gusset for the intersection of the Main Hoop Diagonal and Seat Brace Bar to help strengthen the joint.



We also include the Fire Plates because once the hoop is welded into place on the Package Shelf you will not be able to get a Fire Plate into position after the fact.



For a long time we chose not to do a package shelf version of our roll cage kit due to the fact that it required an S bend in the upper Nascar bar in order to get back to the Main Hoop for attachment.   An S bend has essentially lost all its strengh and is pre-failed.  We took the time to find a way to make the new door bars happen without having to do the S bend and are now offering them in this upgrade kit.



* - The standard roll cage kit does not come with this product, this is simply an upgrade to a different location for mounting the Main Hoop.



THIS IS NOT A COMLETE ROLL CAGE KIT.

All the parts needed to modify the standard   Miata Cage Kit (Not Included) to a version that mounts to the package shelf.

The way this package works is you utilize most all of the parts from the standard floor mount MiataCage Roll Cage Kit and then we supply you with the following to convert it to a package shelf mount.

  • Package Shelf Installation Addendum.  12 pages with pictures and schmatic.
  • (2) Laser cut and formed Main Hoop and Lower Door Bar landing plates
  • 1" Tube Gussets
  • Main Hoop Taco Gusset
  • Fire Plates
  • Re-designed Kill Switch mounting plate
  • (2) New Upper Door Bars
  • Free Shipping in the continental US via UPS Ground service.

The only parts you will not use from the standard Roll Cage Kit would be the upper Nascar bars and the kill switch plate.



Given the location of the main hoop diagonal when installing the main hoop to the package shelf, we felt it necessary to include in the kit the Taco Gusset for the intersection of the Main Hoop Diagonal and Seat Brace Bar to help strengthen the joint.



We also include the Fire Plates because once the hoop is welded into place on the Package Shelf you will not be able to get a Fire Plate into position after the fact.



For a long time we chose not to do a package shelf version of our roll cage kit due to the fact that it required an S bend in the upper Nascar bar in order to get back to the Main Hoop for attachment.   An S bend has essentially lost all its strengh and is pre-failed.  We took the time to find a way to make the new door bars happen without having to do the S bend and are now offering them in this upgrade kit.



* - The standard roll cage kit does not come with this product, this is simply an upgrade to a different location for mounting the Main Hoop.



THIS IS NOT A COMLETE ROLL CAGE KIT.
